ПОДШИПНИК РОЛИКОВЫЙ РАДИАЛЬНЫЙ NU1026-M1
Inner diameter:: 130 mm
Outer diameter: 200 mm
The size of the width: 33 mm
Outer diameter: 200 mm
The size of the width: 33 mm
Технические характеристики из каталога производителя:
- ОбозначениеNU1026-M1
- ПроизводительFAG
- e182 mm
- db min151 mm
- r1 min1,1 mm
- ra1 max1 mm
- d200 mm
- B33 mm
- D1175,9 mm
- Da max146 mm
- da min136 mm
- ra max2 mm
- rmin2 mm
- m3,74 kg / Вес
- Cr212000 N / динамическая грузоподъемность, радиальная
- C0r250000 N / статическая грузоподъемность, радиальная
- nG5700 1/min / Предельная частота вращения
- nB3500 1/min
- Cur31500 N / Нагрузка предела усталости, радиальная
- f148 mm
- S3,9 mm / Осевое перемещение из среднего положения
